3 9 1 2
Same function as option 11, except the output voltage range is 0 to +10
volts.
3 9 1 3
The output voltage is proportional to the guide point value. The output
voltage range is -10 to +10 volts.
3 9 1 4
Same function as option 13, except the output voltage range is 0 to +10
volts.
3 9 1 5
This option is used in resolving-centerline systems only. The output
voltage drives the resolver’s controller. The output voltage range is -10 to
+10 volts.
3 9 1 6
Same function as option 15, except the output voltage range is 0 to +10
volts.
3 9 1 7
This option is used for controlling a servo-valve. The output voltage
reacts to positive web error only. The output voltage range is 0 to +10
volts.
3 9 1 8
This option is used for controlling a servo-valve. The output voltage
reacts to negative web error only. The output voltage range is 0 to +10
volts.
Note: For option 1 the output voltage range and scale depend on several parameters, including
Input Polarity, Servo Gain, Minimum Deadband, Maximum Deadband, and Auto-Mode Speed
Limit. Options 2 through 7 automatically scale the full sensing range of the sensor to the full range
of the analog output, and options 2 and 3 are also affected by Input Polarity.
Analog Offset
4 0 0
The analog offset is off. This is the default setting.
4 0 1
The analog offset source is Analog Input 1. The analog offset polarity is
not inverted.
4 0 2
The analog offset source is Analog Input 1. The analog offset polarity is
inverted.
4 0 3
The analog offset source is Analog Input 2. The analog offset polarity is
not inverted.
4 0 4
The analog offset source is Analog Input 2. The analog offset polarity is
inverted.
Analog Input 1 Range
4 1 0
Analog input 1 is off. This is the default setting.
[continued on next page]
MICRO 4000
NET Controller
27
