Servo Gain and Speed Limit Source
4 8 0
Servo Gain is controlled by parameter 5.
Auto-Mode Speed Limit is controlled by parameter 7.
This is the default setting.
4 8 1
Servo Gain and Auto-Mode Speed Limit are controlled by the optional
Fieldbus Interface (page 102).
4 8 2
Servo Gain is controlled by Analog Input 1.
Auto-Mode Speed Limit is controlled by parameter 7.
4 8 3
Servo Gain is controlled by parameter 5.
Auto-Mode Speed Limit is controlled by Analog Input 1.
Input C Type
4 9 0
Sensor C is not installed. This is the default setting.
4 9 1
Sensor C is an ultrasonic or IR edge detector connected to the Edge
Detector A input.
Note: Set parameter 55 to s
elect sensor type.
4 9 2
Sensor C is a digital line guide connected to the Serial I/O interface.
4 9 3
Sensor C is an external analog device connected to Analog Input 1.
Note: In order to select Input C through the front-panel switchpad, fieldbus, or Discrete Isolated
Inputs, parameter 49 must be set to 1 or higher.
Input C Polarity
5 0 0
The actuator will move Out when edge detector A is unblocked, or the
digital line guide’s sight point is to the left of the line or edge it is
following. This is the default setting.
5 0 1
The actuator will move Out when edge detector A is blocked, or the
digital line guide’s sight point is to the right of the line or edge it is
following.
MICRO 4000
NET Controller
30
