Switchpad Type
5 1 0
Select this option if the input selection buttons on the front-panel
switchpad are labeled EDGE A, CENTERLINE, and EDGE B.
The EDGE A button selects Input A.
The EDGE B button selects Input B.
The CENTERLINE button selects Inputs A and B.
This switchpad does not allow the selection of Input C.
5 1 1
Select this option if the input selection buttons on the front-panel
switchpad are labeled EDGE A, EDGE B, and LINE.
The EDGE A button selects Input A.
The EDGE B button selects Input B.
The LINE button selects Input C.
To select Centerline mode, press the EDGE A and EDGE B buttons
simultan
eously.
5 1 2
Front-panel switchpad operation is the same as option 1.
Bit 7 of the fieldbus Operating Mode Command word selects Automatic
mode. Refer to page 102 for more information about the Fieldbus
Interface. This is the defa
ult setting.
Note: This parameter also affects the operation of the Discrete Isolated Inputs (page 46).
AUXILIARY Input Function
for more information about the AUXILIARY input. Refer to page 46
5 2 0
The AUXILIARY input is off. This is the default setting.
5 2 1
The AUXILIARY input determines which offset is active. To select Offset
2, activate the AUXILIARY input. To select Offset 1, deactivate the
AUXILIARY input.
5 2 2
Same function as option 1, except the polarity of the AUXILIARY input is
inverted.
5 2 3
ctivating the AUXILIARY input will enable Oscillation, and deactivating
it will disable Oscillation. Oscillation parameter 31 must be set to 1 o
higher.
Refer to page 43 for more information about the oscillation function.
5 2 4
Same function as option 3, except the polarity of the AUXILIARY input is
inverted.
5 2 5
Activating the AUXILIARY input will switch the system to Automatic
mode.
5 2 6
Same function as option 5, except the polarity of the AUXILIARY input is
inverted.
[continued on next page]
