5 2 7
Activating the AUXILIARY input will set Offset 1 to the current web
position. This is typically done only during job set-up, when the system is
in Manual or Servo-Center mode.
Note: To reset Offset 1 to its default value, sele
ct parameter 60, then
press the EXIT key.
5 2 8
Same function as option 7, except the polarity of the AUXILIARY input is
inverted.
5 2 9
ctivating the AUXILIARY input will set Offset 2 to the integrator’s input
value and will reset the integrator output. This is typically done only
during job set-up, when the system is in Manual or Servo-Center mode.
Note: To reset Offset 2 to its default value, sele
ct parameter 61, then
press the EXIT key.
5 2 1 0
Same function as option 9, except the polarity of the AUXILIARY input is
inverted.
5 2 1 1
Activating the AUXILIARY input will switch the system to Servo-Cente
mode. The system will return to the previous operating mode when the
AUXILIARY input is deactivated.
5 2 1 2
Same function as option 11, except the polarity of the AUXILIARY inpu
is inverted.
5 2 1 3
Activating the AUXILIARY input will switch the system to Servo-Cente
mode. The system will remain in Servo-Center mode when the
AUXILIARY input is deactivated.
5 2 1 4
Same function as option 13, except the polarity of the AUXILIARY inpu
is inverted.
5 2 1 5
This option is used only for configuring the guide’s AUXILIARY input in
resolving-centerline systems. The AUXILIARY input must be connected
to the resolver’s AUXILIARY output.
5 2 1 6
Same function as option 15, except the polarity of the AUXILIARY inpu
is inverted.
Note: If your application requires a non-isolated AUXILIARY input, then set parameter 72 to 1.
Refer to page 43 for a description of parameter 53.
Drive Configuration
5 4 0
Standard system. The servo-amplifier can be controlled by all inputs.
This is the default setting.
5 4 1
The servo-amplifier can be controlled only by Input C and the integrato
inputs.
5 4 2
The servo-amplifier can be controlled only by the integrator inputs.
MICRO 4000
NET Controller
32
