Sensor A Type
5 5 0
Sensor A is an ultrasonic edge detector. This is the default setting.
5 5 1
Sensor A is an IR edge detector.
5 5 2
Sensor A is a Hi-Temp ultrasonic edge detector.
Sensor B Type
5 6 0
Sensor B is an ultrasonic edge detector. This is the default setting.
5 6 1
Sensor B is an IR edge detector.
5 6 2
Sensor B is a Hi-Temp ultrasonic edge detector.
Servo-Amplifier Fault
5 7 0
The SERVO-AMPLIFIER FAULT input is ignored. This is the default
setting.
5 7 1
If the SERVO-
MPLIFIER FAULT input is high (+5 VDC) and the
SERVO-
MPLIFIER INHIBIT output is not activated, then the controlle
will display a flashing error code. Refer to page
42 for more information
about erro
r codes.
5 7 2
If the SERVO-AMPLIFIER FAULT input is low (0 VDC) and the SERVO-
MPLIFIER INHIBIT output is not activated, then the controller will
display a flashing error code. Refer to page
42 for more information
about erro
r codes.
5 7 3
If the SERVO-
MPLIFIER FAULT input is high (+5 VDC), then the
controller will display a flashing error code. Refer to page
42 for more
information about error codes.
5 7 4
If the SERVO-
MPLIFIER FAULT input is low (0 VDC), then the
controller will display a flashing error code. Refer to page
42 for more
information about error codes.
AUXILIARY Output Function
for more information about the AUXILIARY output. Refer to page 48
5 8 0
The AUXILIARY output is off. This is the default setting.
5 8 1
The AUXILIARY output is on when Sensor A is nulled.
[continued on next page]
MICRO 4000
NET Controller
33
