Integrator Input Offset
7 1 0
The integrator input is not offset. This is the default setting.
7 1 1
This option offsets the integrator input using Offset 1.
7 1 2
This option offsets the integrator input using Offset 2.
INHIBIT and AUXILIARY Input Configuration
This parameter swaps the function of the INHIBIT a
nd AUXILIARY inputs. This is useful when
your application requires either a non-isolated AUXILIARY input, or an opto-isolated INHIBIT
input.
7 2 0
The INHIBIT function is routed through J7 terminal 8 (non-isolated).
The AUXILIARY function is routed through J9 terminal 8 (opto-isolated).
This is the default setting.
7 2 1
The INHIBIT function is routed through J9 terminal 8 (opto-isolated).
The AUXILIARY function is routed through J7 terminal 8 (non-isolated).
Integrator Rate Multiplier
In a typical application this parameter is used to vary Integrato
r Rate with line speed.
7 3 0
The Integrator Rate is equal to the value of parameter 68 (Integrato
Rate). This is the default setting.
7 3 1
nalog Input 1 controls the Integrator Rate. At maximum input voltage
the rate is equal to 100% of the value of parameter 68. At minimum inpu
voltage the rate is equal to 0% of the value of parameter 68.
7 3 2
nalog Input 2 controls the Integrator Rate. At maximum input voltage
the rate is equal to 100% of the value of parameter 68. At minimum inpu
voltage the rate is equal to 0% of the value of parameter 68.
Sensor A Transducer Orientation
This parameter reverses the order of the transducer beams in Sensor A.
7 4 0
This is the default setting. Beam 1 is located at the end of the
transducer closest to the pigtail wiring.
7 4 1
Beam 1 is located at the end of the transducer farthest from the pigtail
wiring.
