2-17
H6500
NOTE: Circuit boards > 10 cm² has been highlighted with the yellow rectangle as
above image shows. Please detach the Circuit boards and follow local
regulations for disposal.
6. Unscrew 1 screw (as blue circle) and
tear off 1 black mylar (as red square) to
remove the Lamp cable.
