Acer H6500 - 2-6 Disassemble Front cover module

Condential
2-8
H6500
2-6 Disassemble Front
cover module
1. Unscrew 3 screw (as yellow circle).
2. Open 2 clips (as yellow square).
3. Disassemble the Front cover module.
4. Tear off 1 black mylar (as green square)
form IR board.
5. Separate IR sensor board and Front
cover module.
IR sensor board
Front cover module
