H6500
Condential
iii
Assemble DMD chip and DMD board 2-28
Assemble Engine module 2-29
Assemble Color wheel module 2-29
Assemble Front cover module 2-30
Assemble Main board module 2-31
Assemble Keypad board and Zoom ring 2-33
Assemble Top cover module 2-34
Assemble Lamp module 2-35
Chapter 3 Troubleshooting
LED Lighting Message 3-1
Main Procedure 3-2
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
OSD Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC Mode 4-4
Calibration 4-7
Video Performance 4-9
Optical Performance Measure 4-10
Others 4-12
Chapter 5 Firmware Upgrade
Equipment Needed 5-1
Get into Firmware download mode 5-2
