6-4 After Data acquisition（Data acquisition）
・ When [Meas Time] is other than
＊＊＊
not receiving the
Ｅ
command
： Data acquisition completed command
ｒ
is issued to PC.
・ In Interval/Repeat mode,
ｒ
is issued every time of the measurement
・ On E command issued, the measurement is terminated even in the Repeat mode.
3233 PC
＜Data format＞ When Lva mode on D1 command (XCH)
００／０１／０５□０２：１５:１６□
X
□１１０ｄＢ+LF
０００ｈ００ｍ1０ｓ+LF
Ｌａｅｑ：□１１０．０□□□Ｌａ０５：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ１０：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ５０：□１１０．０+LF
ＬＭｉｎ：□１１０．０□□□Ｌａ９０：□１１０．０+LF
ＬＭａｘ：□１１０．０□□□Ｌａ１０：□１１０．０+LF+LF
When Lva mode on D0 command, all CH sent (according to X,Y, Z).
Data
００／０１／０５□０２：１５:１６□
X
□１１０ｄＢ+LF
０００ｈ００ｍ1０ｓ+LF
Ｌａｅｑ：□１１０．０□□□Ｌａ０５：□１１０．０+LF
□□□□：□１１０．０□□□Ｌａ１０：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ５０：□１１０．０+LF
ＬＭｉｎ：□１１０．０□□□Ｌａ９０：□１１０．０+LF
ＬＭａｘ：□１１０．０□□□Ｌａ１０：□１１０．０+LF +LF
□ ：Space（20）
+LF：Line feed（0A）
００／０１／０５□０２：１５:１６□
Y
□１１０ｄＢ+LF
０００ｈ００ｍ1０ｓ+LF
Ｌａｅｑ：□１１０．０□□□Ｌａ０５：□１１０．０+LF
□□□□１１０．０□□□Ｌａ１０：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ５０：□１１０．０+LF
ＬＭｉｎ：□１１０．０□□□Ｌａ９０：□１１０．０+LF
ＬＭａｘ：□１１０．０□□□Ｌａ１０：□１１０．０+LF +LF
００／０１／０５□０２：１５:１６□
Z
□１１０ｄＢ+LF
０００ｈ００ｍ1０ｓ+LF
Ｌａｅｑ：□１１０．０□□□Ｌａ０５：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ１０：□１１０．０+LF
□□□□□□□□□□□□□□Ｌａ５０：□１１０．０+LF
ＬＭｉｎ：□１１０．０□□□Ｌａ９０：□１１０．０+LF
ＬＭａｘ：□１１０．０□□□Ｌａ１０：□１１０．０+LF +LF
Data Request command (D1) issued. (XCH)
When D0 command all CH sent.
(According to X,Y, Z)
Data Transfer
Data acquisition
completed command
ｒ
