WORKING WITH THE CONTROL UNIT 5-17
SB1391 Hardware and Setup Guide - Document revision no. 1.14
FIGURE 5-14 Add new motor item dialog box
Action Effect of action
3. Enter the name of the motor and
click OK.
The new motor record dialog box opens with the new
item name displayed in the Motor field (FIGURE 5-
15).
. . . click here.
Either use the arrow keys to move the selection
point here and then press Enter, or . . .
FIGURE 5-15 New motor record dialog box
