Guidance and manufacturer's declaration – electromagnetic immunity
X-MIND unity is intended to be used in the electromagnetic environment specied below. The customer or X-MIND unity operator must
ensure that the device is used in this type of environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment
guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
+/- 6 kV contact
+/- 8 kV air
+/- 6 kV contact
+/- 8 kV air
Floors should be wood, concrete
or ceramic tile. If oors are
covered with synthetic material,
the relative humidity must be at
least 30%
Electrical fast transient/burst
IEC 61000-4-4
+/- 2 kV for power supply lines
+/- 1 kV for input/output lines
+/- 2 kV for power supply lines
Not relevant for input/output
lines
Mains power quality should
conform to that of typical com-
mercial or hospital applications.
Surge
IEC 61000-4-5
+/- 1 kV differential mode
+/- 2 kV common mode
+/- 1 kV differential mode
Not relevant for common mode
Mains power quality should
conform to that of typical com-
mercial or hospital applications.
Voltage dips, short interruptions
and voltage variations on power
supply input lines
IEC 61000-4-11
<5 % U
T
(>95 % dip in U
T
)
for 0.5 cycles
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 seconds
<5 % U
T
(>95 % dip in U
T
)
for 0.5 cycles
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 seconds
Mains power quality should
conform to that of typical com-
mercial or hospital applications.
If the X-MIND unity operator re-
quires continued operation even
during mains power outage,
we recommend powering the
system using a UPS.
Mains frequency
(50/60 Hz) magnetic eld
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic
elds must be at the typical level
of standard mains for commer-
cial or hospital use.
Notes:
• Ut is the AC mains voltage prior to the application of the test level.
