ADC AD-330 User Manual

112144-46 www.adclaundry.com 7
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS (AD-320)
Shaded areas are stated in metric equivalents 4/20/10
* Dryer must be provided with clean, dry, regulated 80 psi +/- 10 psi (5.51 bar +/- 0.69 bar) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
MAXIMUM CAPACITY (DRY WEIGHT) PER POCKET 20 lb
9.07 kg
TUMBLER DIAMETER 27-1/4”
69.2 cm
TUMBLER DEPTH 25”
63.5 cm
TUMBLER VOLUME PER POCKET 8.4 cu ft
237.86 L
TUMBLER/DRIVE MOTOR PER POCKET 1/3 hp
0.25 kW
BLOWER/FAN MOTOR PER POCKET N/A
DOOR OPENING (DIAMETER) 21-1/2”
54.6 cm
DOOR SILL HEIGHT TOP POCKET / BOTTOM POCKET 50-15/16” / 12-3/16”
129.4 cm / 31 cm
WATER CONNECTION 3/4”-11.5 NH (North America)
3/4” B.S.P.T. (Outside North America)
DRYERS PER 20’/40’ CONTAINER 14 / 28
DRYERS PER 48’/53’ TRUCK 34 / 36
VOLTAGE AVAILABLE 100-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 760 lb
344.7 kg
APPROXIMATE SHIPPING WEIGHT 795 lb
360.6 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
HEAT INPUT PER POCKET 60,000 Btu/hr
15,120 kcal/hr
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION N/A
COMPRESSED AIR VOLUME N/A
INLET PIPE CONNECTION PER POCKET 1/2” F.N.P.T.
1/2” B.S.P.T. (CE and Australia Only)
VOLTAGE AVAILABLE 208-416V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 760 lb
344.7 kg
APPROXIMATE SHIPPING WEIGHT 795 lb
360.6 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION N/A
COMPRESSED AIR VOLUME N/A
OVEN SIZE PER POCKET
kW Btu/hr
kcal/hr
15 51,228
12,910
VOLTAGE AVAILABLE 100-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 873 lb
396.0 kg
APPROXIMATE SHIPPING WEIGHT 949 lb
430.5 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
STEAM CONSUMPTION PER POCKET 101 lb/hr
45.8 kg/hr
OPERATING STEAM PRESSURE 125 psi max
8.6 bar
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION PER POCKET 1/8” F.N.P.T.
COMPRESSED AIR VOLUME 0.5 cfh
0.014 cmh
BOILER HORSEPOWER (NORMAL LOAD) PER POCKET 2.9 Bhp
SUPPLY CONNECTION PER POCKET 1” F.N.P.T.
RETURN CONNECTION PER POCKET 3/4” F.N.P.T.
