450239-4 www.adclaundry.com 5

AD-330 / AD-320 Lint Door Assembly

Illus. No. Part No. Qty. Description

18834631White Lint Door Assembly

(includes illus. nos. 1 and 2)

883464 1 Ivory Lint Door Assembly

(includes illus. nos. 1 and 2)

883465 1 Coral Blue Lint Door Assembly

(includes illus. nos. 1 and 2)

824326 1 Stainless Steel Lint Door Assembly

(includes illus. nos. 1 and 2)

21176043Neoprene Gasket Tape (sold by the foot)

31503144#10-32 x 1/2” TORX PLUS

BTN Head Machine Screw

41540114#10-32 Multi-Thread U-Nut
