ADC AD-330 User Manual

450239-4 www.adclaundry.com 11
Coin Vault Assembly
Illus. No. Part No. Qty. Description
18833471AD-330 / AD-320 Coin Box Assembly with Black Faceplate Less Lock
883348 1 AD-330 / AD-320 Black Coin Box Faceplate ONLY
883393 1 AD-330 / AD-320 Black Debit Card / Non-Coin Faceplate
2* 160036 1 ACE
®
Lock Assembly with Key
3* 160136 1 ACE
®
Key ONLY
48833821AD-330 / AD-320 Coin Vault Assembly ONLY
5––––––1AD-330 / AD-320 Bottom Front Panel Assembly Complete with Hinge
(refer to AD-330 / AD-320 Cold Rolled Steel Door Bottom Front Panel on page 15)
615201441/4-20 Free Spin Wash Nut
*Specify key number when ordering.
