ADC AD-330 User Manual

58
ACCESSING UPPER DRYER FAULT RECORDS
PRESS "MED" TO ENTER
PL #07 FAULT
RECORDING.
PRESS "LO" ONE (1)
TIME TO SCAN DOWN
TO PL #07 FAULT
RECORDING.
PRESS "MED" TO ENTER
PROGRAM MENU.
FROM READY MODE
TOGGLE PROGRAM
SWITCH TO UP
POSITION.
PROGRAM MODE
PL #01 CONTROL
SETTINGS
PL #07 FAULT
RECORDING
READY, INSERT
0.25 ¢ TO START
Note: Press "PAUSE" To exit
PL #07 FAULT RECORDING
memory location.
FOR CYCLE
INFORMATION AT THE
TIME OF THE FAULT
OCCURRENCE, PRESS
THE “MED” KEY.
USE THE “HI” AND “LO”
KEYS TO SCAN
THROUGH THE LAST 5
FAULTS THAT THE
CONTROL BOARD
DETECTED.
PRESS"MED" TO
PROCEED.
UPPER DRYER
FAULTS
1: HR=2:00 CODE= Exhaust Temp
Probe Fault
Drying Temp 160°F, Cool Down Time 2 minutes, Cool
Down Temp 100°F
2: HR=2:00 CODE= Exhaust Temp
Probe Fault
