ADC AD-330 User Manual

450239-4 www.adclaundry.com 31
Sail Switch Assembly
Illus. No. Part No. Qty. Description
13192061Sail Switch Damper
802805 1 AD-330 / AD-320 Sail Switch Rod and Damper Assembly
(includes illus. nos. 1 through 3)
21055501AD-330 / AD-320 Sail Switch Rod
315400211/8” Push-On Fastener
41503032#4 x 3/4” Pan Head “A” Machine Screw
51222001Sail Switch ONLY
802807 1 AD-330 / AD-320 Sail Switch Bracket Assembly
(includes illus. nos. 4 through 7)
63192081AD-330 / AD-320 Sail Switch Bracket
71540041Twin Speed Nut
81500012#6-32 x 1/2” Round Head Machine Screw
91530102#6 Star Washer
10 152000 2 #6-32 Hex Nut
