14 American Dryer Corporation 450239-4
AD-330 / AD-320 Cold Rolled Steel Door Top Front Panel
Illus. No. Part No. Qty. Description
18834111AD-330 / AD-320 White Front Panel Assembly
(includes illus. nos. 1 through 3)
822676 1 AD-330 / AD-320 Magnetic Front Panel Assembly
(for models mfd. as of August 14, 2007)
883413 1 AD-330 / AD-320 Ivory Front Panel Assembly
(includes illus. nos. 1 through 3)
883412 1 AD-330 / AD-320 Coral Blue Front Panel Assembly
(includes illus. nos. 1 through 3)
883415 1 AD-330 / AD-320 Stainless Steel Front Panel Assembly
(includes illus. nos. 1 through 3)
215421521/8” Pop Rivet
31703301Friction Door Latch
41503138#10-16 x 1/2” TORX PLUS
®
BTN Head Screw
58811521Black Top Hinge Block Assembly
68811511Black Bottom Hinge Block Assembly
715044541/4-20 x 3/4” Black Screw
810200420.75 Round Door Magnet
91522232#10-32 x 0.5 TORX
®
Screw
