Totally Enclosed, Non-Vent Motor / Idler Assemblies
Illus. No. Part No. Qty. Description
21 101096 1 Front Motor Shaft Bushing (50/60 Hz)
22 153024 1 #10 Lock Washer
23 150216 1 #10-32 x 3/4” Left Hand Phillips Round Head Screw
24 154279 4 5/16-18 x 3/4” Carriage Bolt
25 800917 1 Motor Mount ONLY
803918 1 1/3 hp 120/230v 1ø 60 Hz Totally Enclosed, Non-Vent Motor Mount Assembly Complete
(includes illus. nos. 11 through 28 and 31)
803926 1 1/3 hp 120/230v 1ø 50 Hz Totally Enclosed, Non-Vent Motor Mount Assembly Complete
(includes illus. nos. 11 through 28 and 31)
26 153001 4 5/16” Flat Washer
27 153002 4 5/16” Lock Washer
28 152004 4 5/16-18 Hex Nut
29 137030 1 8-Pin Housing
30 122701 8 Socket Terminal ONLY
122801 1 Pin / Socket Extraction Tool … Not Illustrated
31 116010 1 Felt Motor Seal ONLY
32 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
33 153002 4 5/16” Lock Washer
34 153001 4 5/16” Flat Washer
35 100173 1 12-Rib 95” Belt
36 117604 3 Neoprene Sponge Tape (sold by the foot)
37 153054 1 Motor Washer (for 50 Hz models)
38 100705 1 3/16” x 3/16” x 1-3/8” Key
39 802831 1 12-1/2” Riveted Impellor with 3/4” Bore (for 60 Hz models)
802830 1 12-1/2” Riveted Impellor with 5/8” Bore (for 50 Hz models)
40 153051 1 3/4” Flat Washer (for 60 Hz models)
153054 1 Motor Washer (for 50 Hz models)
41 153040 1 3/4” Lock Washer (for 60 Hz models)
153015 1 5/8” Lock Washer (for 50 Hz models)
42 152025 1 3/4-16 Jam Nut (for 60 Hz models)
152030 1 5/8-18 Jam Nut (for 50 Hz models)
43 153525 2 1/4-20 x 1” Self-Clinching Stud
44 850132 1 Bearing Backup Plate
(includes illus. nos. 43 and 44)
852104 1 Bearing Backup Plate Assembly
(includes illus. nos. 43, 44, and 46 through 48)
45 880885 1 Impellor Cover
46 116011 1 Bearing Felt Seal
47 153007 2 1/4” Lock Washer
48 152002 2 1/4-20 Hex Nut
49 880225 1 1/2” Flange Bearing
50 152014 4 1/4-20 Free Spin Wash Nut
51 314423 1 Belt Guard
52 150212 2 #10-32 x 5/16” Phillips Pan Head Stainless Steel Screw
