7451A/7461A/7461P Digital Multimeter Operation Manual
5.1.2 Menu List
5-5
2 TRIG
DELAY Trigger delay
0 s to 3600 s
N.Smpl Number of samples
1 to 16000
SI Sampling interval
50 s to 3600 s (For 7461A/61P)
200 s to 3600 s (For 7451A)
SRC Trigger source Selection
IMMED/MAN/EXT/BUS/LEVEL/DELTA
LEVEL Level count value (For the trigger source is set to only LEVEL)
-1199999 to 1199999 (For 7461A/61P)
-319999 to 319999 (For 7451A)
SLOPE Slope (For the trigger source is set to only LEVEL)
POSI/NEGA
DELTA Delta count value (For the trigger source is set to only DELTA)
0 to 1199999 (For 7461A/61P)
0 to 319999 (For 7451A)
SLOPE Slope (For the trigger source is set to only DELTA)
POSI/BOTH/NEGA
PATRN Pattern (For the trigger source is set to only DELTA)
EMISS/CONV
P.Trig Pre-trigger (For the trigger source is set to LEVEL or DELTA)
OFF/25%/50%/75%
(b)
(a)
3 CALC
COMP Comparative calculation
OFF/ON
MATH Other calculations
OFF/dB/dBm/SCL
MX/MN MAX/MIN calculation and selecting the display
OFF/ON/MAX/MIN
RSLT Display of the MAX/MIN calculation result
SAMPL/MAX/MIN/AVG
PASS PASS condition settings
LGH/__H/_G_/L__/L_H/LG_/_GH/___
BEEP Calculation Result and buzzer
OFF/PASS/FAIL
SM.CNT Number of times smoothing is performed
2 to 100
times
D.OUT
*7461P only
Digital output enabled/disabled
OFF/ON
Category layer Selection layer Entry/Execution layer
