8230 Optical Power Meter Operation Manual
1.4 Connectable Sensors
1-6
NOTE: The 823x series sensors cannot be used for the optical power meter TQ8210 or TQ8215.
Figure 1-1 Connection Diagram for Sensors
Thin-type three-wavelength optical sensor
Wavelength: 390 to 900 nm
82314B 82314A
Cylindrical type three-wavelength optical sensor
Wavelength: 390 to 900 nm
82324B 82324A
Thin-type large-area three-wavelength optical sensor
Wavelength: 390 to 900 nm
82314BW 82314W
Table 1-3 Old and New Model Numbers of Optical Sensors (2 of 2)
New model number Old model number
82311B OPTICAL SENSOR
82312B OPTICAL SENSOR
82313B OPTICAL SENSOR
