8230 Optical Power Meter Operation Manual
1.6 Options and Accessories
1-8
1.6 Options and Accessories
1.6.1 Option to Use Old-Type Sensors (OPT8230+70)
The 821x series optical sensors (the 82014A, 82017A, 82015, and Q82018A) for the TQ8210 or TQ8215
can be connected to this optical power meter by specifying the option.
1.6.2 Sensor Option
The following options can be used to obtain the wavelength sensitivity correction data or calibration data
of the sensor. Specify the option when ordering.
• Wavelength sensitivity correction option
The wavelength sensitivity of each sensor is measured and corrected when calibrating. (The standard
model of 82311B/82321B is corrected by using the typical value.)
• Additional calibration wavelength option
The calibration is performed at other wavelengths in addition to the standard specification. (Multiple
wavelengths can be specified.)
Table 1-5 Sensor Option
Sensor name
Option
Wavelength sensitivity
correction
Additional calibration wavelength
405 nm 650 nm 780 nm
82311/
82311B
OPT82311+20/
OPT82311B+20
OPT82311+21/
OPT82311B+21
OPT82311+22/
OPT82311B+22
Standard specification
82312/
82312B
Standard specification Standard specification - -
82313/
82313B
Standard specification
OPT82313+21/
OPT82313B+21
Standard specification
OPT82313+23/
OPT82313B+23
82321/
82321B
OPT82321+20/
OPT82321B+20
OPT82321+21/
OPT82321B+21
OPT82321+22/
OPT82321B+22
Standard specification
82322/
82322B
Standard specification Standard specification - -
82323/
82323B
Standard specification
OPT82323+21/
OPT82323B+21
Standard specification
OPT82323+23/
OPT82323B+23
82314A/
82314B
Standard specification Standard specification
OPT82314A+22/
OPT82314B+22
OPT82314A+23/
OPT82314B+23
82314W/
82314BW
Standard specification Standard specification
OPT82314W+22/
OPT82314BW+22
OPT82314W+23/
OPT82314BW+23
82324A/
82324B
Standard specification Standard specification
OPT82324A+22/
OPT82324B+22
OPT82324A+23/
OPT82324B+23
