8230 Optical Power Meter Operation Manual
6.1.2 How to Test the Performance
6-3
The instrument enters the current measurement mode.
3. Remove the sensor, and then connect this instrument and the current generator
(hereafter called VIG) through the TRIAX-12pin conversion adapter A as shown
in Figure 6-1.
4. Open the input and measure ZERO in all ranges. Use the [UP] and [DOWN]
keys to select ranges. Ensure that the accuracy of ZERO is within the accuracy
shown in Table 6-3. (for the 823x series path)
5. Connect the VIG to the input and apply the value shown in Table 6-3 from the
VIG to the instrument and measure FULL in all ranges. Ensure that the accuracy
of FULL is within the accuracy shown in Table 6-3. (for the 823x series path)
6. Replace the TRIAX-12pin conversion adapter A with the TRIAX-12pin conver-
sion adapter B.
7. Open the input and measure ZERO in all ranges. Use the [UP] and [DOWN]
keys to select ranges. Ensure that the accuracy of ZERO is within the accuracy
shown in Table 6-3. (for the 821x series path)
8. Connect the VIG to the input and apply the value shown in Table 6-3 from the
VIG to the instrument and measure FULL in all ranges. Ensure that the accuracy
of FULL is within the accuracy shown in Table 6-3. (for the 821x series path)
CAUTION: If the case or cables are touched or moved in the 20 nA or 200 nA
range, the measured value may become unstable. Perform the mea-
surement when the value becomes stable.
Table 6-3 Current Range Accuracy Specifications
Range
Measurement
point
Specification
823x series path 821x series path
20 nA ZERO 0 A (Open) 300 pA 300 pA
FULL 19 nA 440 pA 460 pA
200 nA ZERO 0 A (Open) 300 pA 300 pA
FULL 190 nA 900 pA 1,300 pA
2 A ZERO 0 A (Open) 1.50 nA 1.50 nA
FULL 1.9 A 4.50 nA 11.5 nA
20 A ZERO 0 A (Open) 15.0 nA 15.0 nA
FULL 19 A 45.0 nA 115 nA
200 A ZERO 0 A (Open) 150 nA 150 nA
FULL 190 A 450 nA 1150 nA
2 mA ZERO 0 A (Open) 1.50 A 1.50 A
FULL 1.9 mA 4.50 A 11.5 A
20 mA ZERO 0 A (Open) 15.0 A 15.0 A
FULL 19 mA 45.0 A
115 A
50 mA ZERO 0 A (Open) 150 A 150 A
FULL 50 mA 225A 400 A
To Next Page
