8230 Optical Power Meter Operation Manual
2.3 Upper Side
2-7
2.3 Upper Side
Refer to 14 in “2.1.1 Function Description”.
Figure 2-4 Top View
2.4 Bottom Side
Refer to 15, 16, and 17 in “2.1.1 Function Description”.
Figure 2-5 Bottom View
14
15
16 17
