8230 Optical Power Meter Oper
ation Manual
7.5 Calibration Operation
7-6
Figure 7-4
IV O
ffset
Calibrati
on Flow
Calibrat
ion mode : CAL1
Input o
pen
Calibration complete
Calibration incomplete
Calibration error
Err 10 is displayed
Calibration mode complete : CAL0
Enters the calibration mode.
Zero calibration : XIVC0
Connect 1 k
Full calibration
XIVC1
Judgm
ent
Calibration complete
Calibration da
ta saved : XWR
T
erminates the calib
ration mode.
95
97
Table of Contents
Default Chapter
13
Table of Contents
13
1 Introduction
21
Product Outline
21
Standard Accessory
21
Standard Accessories
21
Accessories
22
Connectable Sensors
23
Old and New Model Numbers of Optical Sensors
25
Connection Diagram for Sensors
26
Optical Power Meter Software Revisions and Applicable Optical Sensors
27
List of Software Revisions Required for Optical Sensor Operations
27
Options and Accessories
28
Option to Use Old-Type Sensors (OPT8230+70)
28
Sensor Option
28
Operating Environment
29
Battery
29
How to Remove and Replace Batteries
30
Battery Cover
30
Battery Alignment
30
Precautions When Using this Instrument
31
1.10 Checking Operations
31
1.11 Cleaning
32
Cleaning the 8230
32
Cleaning the Incident Surface of the Sensor
32
1.12 How to Store and Transport the Instrument
32
Storage
32
Transportation
32
1.13 Warm-Up
33
1.14 Calibration
33
1.15 Replacing Parts with Limited Life
33
1.16 Product Disposal and Recycle
34
2 Panel and Function Description
35
Front Side
35
Function Description
35
Front View
35
2.1.2 Display Description
39
Battery Indicator
39
Rear Side
40
Rear View
40
Upper Side
41
Bottom Side
41
Top View
41
Bottom View
41
3 How to Perform Measurements
43
Menu Map
43
Menu Description
44
Measurement Procedure
45
Connecting the Sensor
45
Setting the Wavelength
45
Zero Cancel
45
Setting the Range
45
Reading the Display
45
Backing up and Initializing the Setting Parameter
46
Backing up the Setting Parameter
46
Initial Values of the Parameters and Backup
46
How to Initialize
47
Outline of the Parameter Backup
47
Wavelength Preset
48
Setting the Preset Wavelength
48
Setting the Preset Wavelength
49
Calling the Preset Wavelength
50
4 Remote Controlling Via Usb
51
Outline
51
USB Specifications
51
Setting up the USB Port
51
Driver for Control
51
Connecting to a Personal Computer
52
Setting the MYID
52
Response to the *IDN? Command
52
Measurement Data Output Format
54
Status Register
58
Status Register Structure
58
Status Byte Register
59
Device Event Status Register
60
Standard Event Status Register
61
Error Register
62
How to Set the Remote Command
63
Linking a Header to an Argument
63
Command Separator
64
Command Terminator
64
Executing Commands
64
Remote Control Command List
65
Remote Control Commands
65
4.6.2 Remote Control Command List
66
Initial Value
66
Availability
66
4.7 Sample Programs
72
Program Example 1
72
Measurement Image
72
Display
73
Program Example 2
74
Measurement Image
74
5 Technical Notes
77
Principle of Measurement
77
Block Diagram
78
Optical Power Calibration and Wavelength Sensitivity Correction
79
Wavelength Sensitivity Characteristics and Power Calibration of the Sensor
79
Analog out
80
Relationship between the Current Range and the Output Voltage at Analog Output
80
Calibration Wavelength Selection Function
81
6 Performance Test
83
Performance Test for the 8230
83
Cable and Adapters Required for Performance Test
83
Instruments Required for Current Measurement Calibration and Performance
83
6.1.1 How to Connect Instruments
84
How to Test the Performance
84
Connection Diagram for Performance Test
84
Current Range Accuracy Specifications
85
Performance Test for Optical Sensors
87
Equipment Required for Evaluating Optical Sensors
87
6.2.1 How to Connect the Instrument
88
Calibration Point and Judgment Criteria
88
Connection Diagram for the Optical Sensor Performance Test
88
Judgment Criteria for the Optical Sensor
88
Test Procedure
89
7 Calibration
91
Measuring Instrument, Cable, and Other Instruments Required for Calibration
91
Cables, Adapters, and Others Required for Calibration
91
Precautions
92
How to Connect the Instrument
93
Connection Diagram for the IV Offset Calibration
93
Connection Diagram for the Current Measurement Calibration
93
Current Measurement Calibration Point and Its Allowable Range
94
Current Measurement Calibration
94
Calibration Point and Its Allowable Range
94
Calibration Operation
95
Calibration Flow
95
Current Measurement Calibration Flow
97
Calibration Procedure
98
Offset Calibration
98
Current Measurement Calibration
98
8 Specifications
101
Instrument Specifications
101
General Specifications
103
Standard Accessories
103
Optical Sensor Specifications
104
Sensor Specifications (Sold Separately)
104
Wavelength Sensitivity Correction Option and Additional Calibration Wavelength Option
107
Appendix
109
Trouble Shooting (before Asking for Repair
109
Problem and Solution
109
A.2 Error Messages
110
Error Message
110
Causes of the Generated Calibration Errors
111
82311 B/82312B/82313B/82314B
113
Dimensional Outline Drawing
113
4
Based on 1 rating
Ask a question
Give review
