8230E Optical Power Meter Operation Manual
1. INTRODUCTION
1-1
1. INTRODUCTION
This chapter describes the following items: accessories, recommended operating environment, precautions
when using this instrument, how to use this instrument, controlling by remote, how to verify the specifica-
tions, and specifications.
Please read this manual carefully before using this instrument.
1.1 Product Outline
The 8230E optical power meter is compact and lightweight. Various connector-removable-type optical sen-
sors are provided so appropriate sensors can be attached according to the intended usage when performing a
measurement. Each sensor is calibrated at a set wavelength to allow highly accurate measurements to be per-
formed.
Also, optical sensors for the TQ8210 or TQ8215 can be used by specifying option 70.
However, this function is applied to software revision C00 or later.
The 8230E includes two types of power supply system; an AC power supply and a battery, so that the mea-
surements can be performed continuously under the following two conditions; measurements while on the
move, and measurements when connected to the AC power supply.
Data measurements and automatic measurements can be performed easily in a laboratory or production line
by using the supplied USB digital interface.
The 8230E includes a 4-1/2 digit backlit LCD display, which can be read easily regardless of the surrounding
brightness or darkness.
1.2 Standard Accessory
The standard accessories, which are included in this instrument, are shown below. If any equipment is dam-
aged or missing, contact an ADC CORPORATION sales representative. Quote the model name when order-
ing.
Table 1-1 Standard Accessories
Accessory name Model name Quantity Remarks
AC adaptor A146001 1 AC100V-240V
8230E operation manual E8230E 1
To Next Page
