8230E Optical Power Meter Operation Manual
6. PERFORMANCE TEST
6-1
6. PERFORMANCE TEST
This chapter describes the procedures used to check whether this instrument (8230E) and the sensors
(82311B, 82313B, 82321B, and 82323B) operate correctly within the specified accuracies.
6.1 Performance Test for the 8230E
Instruments required for the performance test of this instrument are shown below:
Table 6-1 Cable and Adapters Required for Performance Test
Cable and adapters Remarks
TRIAX-12pin conversion adapter A (A185002) For the 823x series sensor path
TRIAX-12pin conversion adapter B For the 821x series sensor path
A01009 TRIAX-TRIAX cable
Table 6-2 Instruments Required for Current Measurement Calibration and Performance
Range
[ZERO] [FS]
Recommended
instrument
Calibration point Calibration point Required accuracy [A]
20 nA
0 A
(Input open)
19 nA 106 pA
6245
(FS only)
200 nA 190 nA 436 pA
2 A1.9 A 1.42 nA
20 A 19 A 12.3 nA
200 A 190 A 104 nA
2 mA 1.9 mA 1.04 A
20 mA 19 mA 10.4 A
50 mA 50 mA 18.1 A
