8230E Optical Power Meter Operation Manual
8.1.2 General Specifications
8-3
8.1.2 General Specifications
8.1.3 Standard Accessories
8.1.4 Option
Item Specification
Operating environment Environmental temperature: 0 to +40C.
Relative humidity: 80% or less with no condensation
Storing environment Environmental temperature: -20 to +70C.
Relative humidity: 80% or less with no condensation
Warm-up time 30 minutes or more (to achieve prescribed accuracy)
Power supply 4 AA size batteries *4
Battery life: 60 h (with 1 mW or less power, with back light OFF, using the
alkaline dry battery, and at +23 C 5 C)
DC input: 9 V 100 mA or less
AC adapter: AC100 V-240 V
Power supply frequency: 50/60 Hz
Power consumption: 100 to 120 V: 5 VA or less, 220 to 240 V: 10 VA or less
(when using the standard accessory)
External dimensions Approx. 80 (width) x 180 (height) x 40 (depth) mm
Mass 300 g or less (excluding AA batteries)
*4 Batteries are not included.
Item Model Quantity Remarks
AC adaptor A146001 1 AC100V-240V
Operation manual E8230E 1 English
Option to use old-type sensors OPT8230E+70 821x series:
The 82014A, 82017A, (82015, or
Q82018A *5 ) can be used.
*5: The 82015/Q82018A has been discontinued.
To Next Page
