8230E Optical Power Meter Operation Manual
6.2 Measuring Instruments and Other Equipment Required to Check the Performance of the Optical Sensor
6-5
6.2 Measuring Instruments and Other Equipment Required to Check the Performance
of the Optical Sensor
To calibrate the optical sensors, the light source, optical fiber, standard optical power meter, all of which meet
the specifications described below, as well as a measuring environment with little or no vibration, at a tem-
perature of +23 C 5 C, and a temperature change of 1 C are required.
Table 6-4 Equipment Required for Evaluating Optical Sensors
Product
Light source
Fiber FC adaptor
Wavelength Output Stability
82311B 780 nm 1 mW 0.20% PMF/SMF or GI50m WBL-Q17ADAPTER
82313B 650 nm 1 mW 0.20% PMF/SMF WBL-Q82313ADAPTER
82321B 780 nm 1 mW 0.20% PMF/SMF or GI50m A08012
82323B 650 nm 1 mW 0.20% PMF/SMF A08012
8230E/8230/8250A For connecting a sensor
Optical power meter Standard Must be calibrated at an accuracy of 0.8% or less
for each wavelength.
To Next Page
