ADCMT 8230E User Manual

8230E Optical Power Meter Operation Manual
4.7.2 Program Example 2
4-24
Next cnt
err_exit:
ret = ausb_close(OPM1) 'Closes the device.
If ret <> OK Then 'If the device is closed incorrectly
MsgBox "device CLOSE error", vbExclamation
End If
ret = ausb_end() 'USB terminates.
If ret <> OK Then 'If the USB connection terminates incor-
rectly
MsgBox "USB end error", vbExclamation
End If
End Sub
Sub acquires the data (). 'Subroutine for the START button on the
sheet.
enterF = 1 'Sets the flag of the ENTER input button to
ON.
End Sub
4.7.2 Program Example 2
Acquires measurement data from the two connected 8230 or 8230Es.
Figure 4-3 Measurement Image
Program list
Option Explicit 'All variables are explicitly declared.
Private Const OK As Integer = 0 'Defines OK.
Sub Starts to control two sets of 8230.
'Subroutine for the START button on the
sheet.
Dim OPM1 As Long 'USB handle

ADCMT 8230E Specifications

General

Brand	ADCMT
Model	8230E
Category	Measuring Instruments
Language	English
