4.4 Measurement Data Output Format
4-6
Number of displayed digits.
Unit display
Number of
displayed
digits.
Mantissa
Number of
characters
Initial
value
W
RATIO
4 1/2

7
3 1/2

6
dBm
dBr
4 1/2 ddd.dd (2,000 counts or more when
W is displayed.)
7
ddd.dd (Between 500 and 1,999
counts when W is dis-
played.)
0ddd.d (Between 50 and 499 counts
when W is displayed.)
00ddd. (Less than 50 counts when
W is displayed.)
3 1/2 ddd.d (2,000 counts or more when
W is displayed.)
6
ddd.d (Between 500 and 1,999
counts when W is dis-
played.)
ddd.d (Between 50 and 499 counts
when W is displayed.)
0ddd. (Less than 50 counts when
W is displayed.)
