8230E Optical Power Meter Operation Manual
Preface-1
PREFACE
This manual describes how to use the 8230E, its specifications, and how to use the 8230E by remote control.
1. Organization of this manual
This manual consists of the following chapters:
Safety Summary Read the safety instructions before operat-
ing this instrument.
1. INTRODUCTION
Describes the following items: product
overview, accessories, operating environ-
ment, and precautions to be taken when
using this instrument. Read this chapter
before operating this instrument.
2. PANEL AND FUNCTION DESCRIPTION
• Front Side
• Rear Side
• Upper Side
• Bottom Side
Describes the names of each part of the
panel and their functions as well as the dis-
play section.
3. HOW TO PERFORM MEASUREMENTS
•Menu Map
• Menu Description
• Measurement Procedure
• Backing up and Initializing the Setting Parameter
The user can learn how to use this instru-
ment.
4. REMOTE CONTROLLING VIA USB
Describes how to control this instrument
by remote. Example programs are pro-
vided.
5. TECHNICAL NOTES
• Principle of Measurement
• Optical Power Calibration and Wavelength Sen-
sitivity Correction
• ANALOG OUT
Describes supplementary technical infor-
mation on this instrument.
6. PERFORMANCE TEST
• Performance Test for the 8230E
• Measuring Instruments and Other Equipment
Required to Check the Performance of the Opti-
cal Sensor
Describes how to test the performance of
this instrument.
7. CALIBRATION
Describes how to calibrate this instrument
to use it within the specified accuracy.
8. SPECIFICATIONS
• 8230E Specifications
• Optical Sensor Specifications
Describes the 8230E and optical sensor
specifications.
A.1 Trouble Shooting (Before Asking for Repair)
A.2 Error Messages
Describes messages which are displayed
on the 8230E and other information.
