Lesson 5 Servo 90 degree adjustment
Before assembling the robotic arm, we first need to adjust the 5 servos of the
robotic arm by 90 degrees.
5.1 Components used in this course
Components
Quantity
Adeept Arm Drive Board
1
Micro USB Cable
1
Servo
5
5.2 Wiring diagram (Circuit diagram)
Connect 5 servos to the Servo1, Servo2, Servo3, Servo4, Servo5 ports on the
Adeept Arm Drive Board:
