Connect five servos to the Adeept Arm Drive Board.
6.1.3 Turnplate and Rocker Arm Assembly
Servo debugging（If you have already adjusted the steering gear to 90 degrees according to
Lesson 5, then you don’t need to adjust it anymore, please proceed to the next part）
`
Connect No. 1-5 servo, and increase from
No. 1-5 in the direction close to the oled
screen. Note that the direction of the Servo
interface should not be reversed
For convenience to read, only one
end of the servo power cable is
shown here.
