Network Camera
V1.0 45
Specifications
LENS
Lens Type Fixed focal lens (F2.0)
Focal Length 3.8 mm
CAMERA
Image Sensor 1/4" CMOS
Minimum Illumination IR LED Off: 1 Lux @ F2.0, IR LED On: 0 Lux @ F2.0
Scanning Mode Progressive scan
SNR 50 dB
Electronic Shutter Auto
External Storage SD (SDHC) memory card (class 6 or higher)
VIDEO
Compression Algorithm H.264, M-JPEG (Four levels)
Compression Resolution 320x240, 640x480
Bitrate Control H.264 – CBR (up to 4 Mbps)
Maximum Frame Rate
(images per second)
30 ips @ 640x480 + 30 ips @ 640x480
Dual Stream Live monitoring & Recording, Live monitoring
AUDIO
Compression Algorithm G.726 (16KHz), G.711 μ – Law (8KHz)
INPUTS/OUTPUTS
Audio Input 1 line in
Audio Output 1 line out
Network Connectivity 10/100 Mbps Ethernet
CONNECTORS
Audio In/Out Terminal block (mono)
Ethernet Port RJ-45
GENERAL
Dimensions (Ø, W x H x D) 3.1", 5.3" x 3.6" x 4.6" (80mm, 134mm x 90.8mm x 116mm)
Shipping Dimensions
(W x H x D)
7.9" x 5.0" x 5.7" (200mm x 127mm x 144mm)
Unit Weight 0.9 lbs. (0.42kg)
Shipping Weight 1.8 lbs. (0.8kg)
Operating Temperature 32°F to 122°F (0°C to 50°C)
Operating Humidity 0% to 90%
Power Supply 12 VDC, PoE (Power over Ethernet) (IEEE 802.3af, Class 0)
Power Consumption Max. 5W
Approval FCC, CE, UL*
* CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries
According to the Instructions. This equipment is indoor use and all the communication wiring are limited
to inside of the building.
Specifications are subject to change without notice.
