ADTECH9 Series CNC Maintenance Manual
- 152 -
042 X axis pitch compensation spacing (mm)
Y axis pitch compensation spacing (mm)
Z axis pitch compensation spacing (mm)
A axes pitch compensation spacing (mm)
B axis pitch compensation spacing (mm)
C axis pitch compensation spacing (mm)
Range : 1~1000
Unit : mm
Authority : Super Admin
Default : 10
Effective time : Instant
Note : Set the compensation spacing from point N to point N + 1 of each axis; if
it is set to 10mm, the spacing from compensation point 0 to 1 is 10mm.
043 X axis pitch compensation start position
Y axis pitch compensation start position
Z axis pitch compensation start position
A axes pitch compensation start position
B axis pitch compensation start position
C axis pitch compensation start position
Range : -9999.999 ~ 9999.999
Unit : mm
Authority : Super Admin
Default : 0
Effective time : Instant
Note : Set the starting position of compensation, which corresponds to the
machine coordinate position. Since the number of pitch compensation is
measured from mechanical zero position to a position on the machine, so
that the parameter is set to the mechanical zero position. The parameter is
generally set to 0.
044 X axis pitch compensation end position
