ADTECH9 Series CNC Maintenance Manual
- 155 -
Z Servo Driver Type
A Servo Driver Type
B Servo Driver Type
C Servo Driver Type
Range : Standard pulse type QX, QS8 .... ETherCAT bus type servo driver
Unit :
Authority : Super Admin
Default : Standard Pluse Mode
Effective time : Instant
Note : It is used to set the standard pulse type and ETherCAT bus type of the
servo driver types
049 X encoder type
Y encoder type
Z encoder type
A encoder type
B encoder type
C encoder type
Range : Relative, absolute
Unit :
Authority : Super Admin
Default : Standard Pluse Mode
Effective time : Instant
Note : To set the servo driver encoder type
050 X Server Orientation Output Port No.
Y Server Orientation Output Port No.
Z Server Orientation Output Port No.
A Server Orientation Output Port No.
B Server Orientation Output Port No.
C Server Orientation Output Port No.
Range : 0~8888
Unit :
