9. While the samples in the first cassette are being tested, addition-
al samples in the batch to be tested may be loaded into the next
and subsequent cassettes (in the order scanned by the barcode
reading device, if enabled).
CAUTIONS
a. The operating head constitutes a moving part while the
instrument is in operation; use care to avoid injury to your-
self and damage to the instrument whenever introducing
any part of the body inside the cover during operation.
b. Be careful not to place a cassette behind the cassette pusher
when it is in operation.
c. If operating in a low humidity environment, use the evapo-
ration cover to minimize sample loss due to evaporation.
36
The Advanced
®
Model 4C3 User’s Guide
Figure 9: Operating Head Loading or Unloading a
Sample Tube
