A.C. Output from fuse F6 and load side of
accessory triac Q12. Energizing for .5
seconds when web stops if TT printer selected
or for an adjustable dwell in the HS mode.
Check fuse F6 if neon N5 stays on and
accessory will not cycle at end of bagger
cycle and either Printer TT or HS is selected
in printer setup screen. (See notes for J5-11.)
A.C. Voltage
Only (120 V.
A.C. For
P-100)
Local Neutral J5-4,5
(5th & 6th terminal)
if Jumpered In J3
Aux. Port or Other
Accessory Common
J5-12
A.C. input to high side of accessory traic
Q12. Voltage furnished by jumpers in J3
Aux. Port Plug or remote accessory. N5 neon
is lit if line voltage is present and triac circuit
is off. N5 is shunted by the triac and
extinguishes when the triac turns on to
energize hot stamp printer or other remote
accessory. (See notes for J5-12.)
A.C. Voltage
Only (120 V.
A.C. For
P-100)
Local Neutral J5-4,5
(5th & 6th terminal)
if Jumpered In J3
Aux. Port or Other
Accessory Common
J5-11
-90 to -100 volts D.C. brake drive voltage.
Lights N6 neon (one electrode) when voltage
is applied while machine is stopped with
motor running. (Check F3 if no light after
pressing STOP and the START.) (Turn off
machine power and unplug J5. Measure 1040
ohms on brake terminals.)
90 to 100 V.
D.C.
J5-9 (10th terminal)J5-10
+90 to +100 volts D.C. brake drive voltage.
Lights N6 neon (one electrode) when voltage
is applied while machine is stopped with
motor running. (Check F3 if no light after
pressing STOP and then MAN.) (Turn off
machine power and unplug J5. Measure 1040
ohms on brake terminals.)
90 to 100 V.
D.C.
J5-10 (11th
terminal)
J5-9
-90 to -100 volts D.C. Clutch drive voltage.
Lights N1 neon (two electrodes) and N7 neon
(one electrode) when voltage is applied while
machine is advancing bags. (Check F2 if no
light and bags do not advance after seal
cycle.) (Turn off machine power and unplug
J5. Measure 1040 ohms on clutch terminals.)
90 to 100 V.
D.C.
J5-6 (7th terminal)J5-8
Switched 120 volt a.c. to High Voltage
Sensing Board. Provides primary voltage to
high voltage transformer.
120 V. A.C.J5-4,5 (5th & 6th
terminal)
J5-7
+90 to +100 volts D.C. clutch drive voltage.
Lights N1 neon (two electrodes) and N7 neon
(one electrode) when voltage is applied while
machine is advancing bags. (Check F2 if no
light and bags do not advance after seal
cycle.) (Turn off machine power and unplug
J5. Measure 1040 ohms on clutch terminals.)
90 to 100 V.
D.C.
J5-8 (9th terminal)J5-6
neutral 1 on 120 volt A.C. (Not jumpered on
230 volt machines.)
138
