5.1 Analog Input Common Command Set
Command Syntax Description I/O Module
%AANNTTCCFF Sets the address, input range,
baud rate, data format, checksum
status, and/or integration time for
a specified analog input module
4011, 4011D, 4012, 4013, 4015,
4015T, 4016, 4017, 4017+, 4018,
4018+, 4018M, 4019+
$AA2 Returns the configuration parame-
ters for the specified analog input
module
4011, 4011D, 4012, 4013, 4015,
4015T, 4016, 4017, 4017+, 4018,
4018+, 4018M, 4019+
$AAF Returns the firmware version
code from the specified analog
input module
4011, 4011D, 4012, 4013, 4015,
4015T, 4016, 4017, 4017+, 4018,
4018+, 4018M, 4019+
$AAM Returns the module name from
the specified analog input module
4011, 4011D, 4012, 4013, 4015,
4015T, 4016, 4017, 4017+, 4018,
4018+, 4018M, 4019+
#AA Returns the input value from a
specified analog input moudule in
the currently configured data for-
mat
4011, 4011D, 4012, 4013, 4015,
4015T, 4016, 4017, 4017+, 4018,
4018+, 4019+
#AAN Returns the input value from
channel number n of the specified
analog input module
4015, 4015T, 4017, 4017+, 4018,
4018+, 4018M, 4019+
$AA5VV Enables/disables multiplexing
simultaneously for separate chan-
nels of the specified input module
4015, 4015T, 4017, 4017+, 4018,
4018+, 4018M, 4019+
$AA6 Ask the specified input module to
return the status of all eight chan-
nels
4015, 4015T, 4017, 4017+, 4018+,
4018, 4018M, 4019+
$AA0 Calibrate the analog input module
to correct for gain errors
4011, 4011D, 4012, 4013, 4016,
4017, 4018, 4018M
$AA1 Calibrate the analog input module
to correct for offset errors.
4011, 4011D, 4012, 4013, 4016,
4017, 4018, 4018M
#** Orders all analog input modules to
sample their input values and
store them in special registers
4011, 4011D, 4012, 4013, 4015,
4015T, 4016
$AA4 Returns the value that was stored
in the specified module's register
after the #** command
4011, 4011D, 4012, 4013, 4015,
4015T, 4016
$AAB Ask the module to respond
whether the wiring is open or
closed
4011D, 4015, 4015T, 4018+,
4019+
$AA3 Returns the value of the CJC sen-
sor for a specified analog input
module
4011, 4011D, 4018, 4018+,
4018M, 4019+
$AA9 Calibrates the CJC sensor for
offset errors
4011, 4011D, 4018, 4018+, 4018M
4019+
$AA0Ci Calibrates a specified channel to
correct for gain errors
4015, 4015T, 4017+, 4018+, 4019+
$AA1Ci Calibrates a specified channel to
correct for offset errors
4015, 4015T, 4017+, 4018+, 4019+
