145 ADAM-4000 Series User Manual
Chapter 5 Analog Input Module Commands
5.2 Analog Input Data Logger Command Set
4018M
5.2.1 @AACCCSDMTTTT
Name Set Memory Configuration command
Description Sets the channel storage status, standalone mode, data
logger mode storage type and sampling interval for the
specified analog input data logger.
Syntax @AACCCSDMTTTT(cr)
@ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog input data logger.
C is the Set Memory Configuration command.
CC (range 00-FF) represents the data storage status of each
channel. The ADAM-4018M has 8 channels, bit 0
representing channel 0, and bit 7 representing channel 7. A
mask bit value of ‘1’ enables data storage in the specified
channel, while a mask bit value of ‘0’ disables data storage.
Command Syntax Command Name Description I/O Module
@AACCCSDMTT TT Set Memory
Configuration
Set the channel storage status,
standalone mode, data logger
mode, storage type and sampling
interval for the specified analog
input data logger.
4018M
@AAD Read Memory
Configuration
Return the configuration parame-
ters for the specified analog input
data logger.
4018M
@AASO Set Memory
Operation Mode
Start/stop the recording function
of the memory module.
4018M
@AAT Read Memory
Operation Mode
Read the recording status of the
memory module.
4018M
@AAL Event Record
Count
Read the number of stored event
records in the memory module.
4018M
@AAN Standard Record
Count
Read the number of stored
standard records in the memory
module.
4018M
@AARNNNN Read Record
Content
Read the contents of the specified
record.
4018M
@AAACSDHHHH
TEIIII
Set Alarm Limit Set the high/low alarm settings for
the specified channel.
4018M
@AABC Read Alarm Limit Read the high/low alarm settings
for the specified channel.
4018M
