ADAM-4000 Series User Manual 328
B.2 Analog Input Ranges
Range Code
(hex)
Input Range
Description
Data Formats +F.S. Zero -F.S.
Displayed
Resolution
00 ± 15 mV
Engineering
Units
+15.000 ±00.000 -15.000 1 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
01 ± 50 mV
Engineering
Units
+50.000 ±00.000 -50.000 1 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
02 ± 100 mV
Engineering
Units
+100.00 ±000.00 -100.00 10 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
03 ± 500 mV
Engineering
Units
+500.00 ±000.00 -500.00 10 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
04 ± 1 V
Engineering
Units
+100.00 ±0.0000 -1.0000 100.00 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
05 ± 2.5 V
Engineering
Units
+2.5000 ±0.0000 -2.5000 100.00 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
06 ± 20 mV
Engineering
Units
+20.000 ±00.000 -20.000 1 µv
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
07 ± 4~20mA
Engineering
Units
+20.000 ±00.000 -20.000 1 µA
% of FSR +100.00 ±000.00 -100.00 0.01%
Twos
Complement
7FFF 0000 8000 1 LSB*
08 ± 10 mV
Engineering
Units
+10.000 ±00.000 -10.000 Resolution
% of FSR +100.00 ±000.00 -100.00 1 µv
Twos
Complement
7FFF 0000 8000 0.01%
