Chapter 5 Analog Input Module Commands
4011, 4011D, 4012, 4013, 4015, 4015T, 4016,
4017, 4017+, 4018, 4018+, 4018M, 4019+
5.1.1 %AANNTTCCFF
Name Configuration command
Description Sets address, input range, baud rate, data format, checksum status,
and/or integration time for an analog input module.
Syntax %AANNTTCCFF(cr)
% is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of the analog input module you want to configure.
NN represents the new hexadecimal address of the analog
input module. Range is from 00h to FFh.
TT represents the type (input range) code. (Note: 4015 and
4019 must be 00)
(Refer to Table 5-1 on Page 5-6)
CC represents the baud rate code.
(Refer to Table 5-2 on Page 5-8)
FF is a hexadecimal number that equals the 8-bit parameter
representing the data format, checksum status and
integration time. The layout of the 8-bit parameter is shown
in Figure 5-1. Bits 2 through 5 are not used and are set to 0.
(cr) is the terminating character, carriage return (0Dh)
$AA7CiRrr Configure the input type and
range of the specified channel in
an analog input module
4015, 4015T, 4017+, 4018+, 4019+
$AA8Ci Get the input type and range of the
specified channel in an analog
input module
4015, 4015T, 4017+, 4018+, 4019+
$AAXnnnn Communication Watchdog Timer
Setting
4015, 4015T, 4017+, 4018+,4019+
$AAY Read Communication Watchdog
Timer Setting
4015, 4015T, 4017+, 4018+, 4019+
$AAS0 Internal self-calibration for offset
and gain errors
4015, 4015T
$AAS1 Reload factory default calibrating
parameter to overwrite current cal-
ibrating parameter
4015, 4015T
