ADAM-4000 Series User Manual 52
The jumper setting of ADAM-4019+ for input type selection:
Note: With built in 120 resister inside.
3.9.1 Application Wiring
Figure 3.36 ADAM-4019+ Universal Analog Input Wiring Diagram
