103 AIMB-785 User Manual
Appendix B I/O Pin Assignments
88h DMA Controller DMA Controller and
LPC, PCI, or PCIe
DMA
89h–8Bh DMA Controller DMA Controller DMA
8Ch–8Eh DMA Controller DMA Controller and
LPC, PCI, or PCIe
DMA
8Fh DMA Controller DMA Controller DMA
90h–91h DMA Controller DMA Controller DMA
92h Reset Generator Reset Generator Processor I/F
93h–9Fh DMA Controller DMA Controller DMA
A0h–A1h Interrupt Controller Interrupt Controller Interrupt
A4h–A5h Interrupt Controller Interrupt Controller Interrupt
A8h–A9h Interrupt Controller Interrupt Controller Interrupt
ACh–ADh Interrupt Controller Interrupt Controller Interrupt
B0h–B1h Interrupt Controller Interrupt Controller Interrupt
B2h–B3h Power Management Power Management Power Management
B4h–B5h Interrupt Controller Interrupt Controller Interrupt
B8h–B9h Interrupt Controller Interrupt Controller Interrupt
BCh–BDh Interrupt Controller Interrupt Controller Interrupt
C0h–D1h DMA Controller DMA Controller DMA
D2h–DDh RESERVED DMA Controller DMA
DEh–DFh DMA Controller DMA Controller DMA
F0h FERR# / Interrupt
Controller
FERR# / Interrupt
Controller
Processor I/F
170h–177h SATA Controller, PCI,
or PCIe
SATA Controller, PCI,
or PCIe*
SATA
1F0h–1F7h SATA Controller, PCI,
or PCIe
SATA Controller, PCI,
or PCIe
SATA
200h–207h Gameport Low Gameport Low Forwarded to LPC
208h–20Fh Gameport High Gameport High Forwarded to LPC
376h SATA Controller, PCI,
or PCIe
SATA Controller, PCI,
or PCIe
SATA
3F6h SATA Controller, PCI,
or PCIe
SATA Controller, PCI,
or PCIe
SATA
4D0h–4D1h Interrupt Controller Interrupt Controller Interrupt
CF9h Reset Generator Reset Generator Processor I/F
