2.1 Introduction
You can access most of the connectors from the top of the board as it is being
installed in the chassis. If you have a number of cards installed, you may need to par-
tially remove a card to make all the connections.
2.2 Parallel Port (LPT1)
The parallel port is normally used to connect the motherboard to a printer. The AIMB-
785 includes an onboard parallel port, accessed through a 25-pin flat-cable connec-
tor, LPT1.
2
3
25
LPT1
