3 AIMB-785 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket Core i7/i5/i3, Pentium and Celeron processor.
L3 Cache: Please refer to CPU specification for detailed information.
BIOS: AMI SPI BIOS (128Mbit)
System Chipset: Q170
SATA Hard Disk Drive Interface: AIMB-785 supports six SATA III ports. SATA2-
SATA5 provides RAID functions (RAID 0, 1, 5, 10).
1.3.2 Memory
RAM: Up to 64 GB in four 288-pin DIMM sockets. Supports dual-channel DDR4
1866/2133 SDRAM.
– AIMB-785: supports non-ECC unbuffered DIMMs and do not support any
memory configuration that mixes non-ECC with ECC unbuffered DIMMs
1.3.3 Input/Output
PCIe slot: 1 PCIe x16 expansion slot, 3 PCIe x4 expansion slot.
PCI Bus: 3 PCI slots, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: Configured to LPT1 or disabled. Standard DB-25
female connector cable is a optional accessory. Because Intel Q170 do not offer
LPC DMA function, the parallel port only supports SPP/EPP.
Serial port: Six serial ports, one is RS-232/422/485 with hardware auto-flow
control and four are RS-232. One DB-9 connector with RS-232 located in rear
panel.
USB port: Supports 6 USB 3.0 ports on front/rear I/O, 6 USB 2.0 ports with
wafer box, and 1 USB 2.0 port with type A connector. rates up to 5 Gb/s.
LPC: One LPC connector to support Advantech LPC modules, including PCA-
COM232-00A1E, PCA-COM485-00A1E, and PCA-TPM-00A1E.
GPIO: AIMB-785 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
Note! The Intel 7th generation processors only support Windows 10 (64-bit).
Note! A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.
Note! AIMB-785 do not support PS/2 connector for PS/2 key board/ mouse.
Please use the USB ports in rear I/O.
