Advantech AIMB-785G2-00A2 User Manual

7 AIMB-785 User Manual
Chapter 1 Hardware Configuration
Figure 1.2 I/O connectors
1.6 AIMB-785 Block Diagram
Figure 1.3 AIMB-785 Block Diagram
LGA1151
Processor
Q170
DMI
DVI-D
DDR4 1866/2133 16GB
DDR4 1866/2133 16GB
Level shifter
Channel A
DDR4 1866/2133 16GB
DDR4 1866/2133 16GB
Channel B
1 PCIex16 slot
PCIex16 Gen3
LAN1: I219LM
PCA-TPM-00A1E (Optional)
LAN2: I211 AT
3 PCIex4 slots
3 PCIex4 Gen3
PCIex1
PCIex1
2nd Super
IO Fintek
F81216AD
NuvoTon
NCT6776D
LPC
ITE 8896 3 PCI slots
1 RS-232/422/485
3 RS-232
2 RS-232
1 LPT (SPP/EPP)
8 bit GPIO
4 SATA III
SATA III 600MB/s
With SW RAID
2 SATA III
SATA III 600 MB/s
Via Marvell 9186A2
6 USB III
DVI-D
Level shifter
USB3.0 5Gbps
1 USB Type A
USB2.0 480Mbps
6 USB II
USB2.0 480Mbps
Audio Module
HD Audio interface
128 Mbit
BIOS Flash
SPI
VGA
PCIex1
