AIMB-785 User Manual 56
 Primary PEG
Select PEG0/PEG1/PEG2/PEG3 graphics device should be Primary PEG.
 Primary PCIE
Select Auto/ PCIE1/ PCIE2/ PCIE3/ PCIE4/ PCIE5/ PCIE6/ PCIE7 of D28: F0/
F1/ F2/ F3/ F4/ F5/ F6/ F7, PCIE8/PCIE9/PCIE10/PCIE11/PCIE12/PCIE13/
PCIE14/PCIE15 of D29: F0/ F1/ F2/ F3/ F4/ F5/ F6/ F7/, PCIE16/ PCIE17/
PCIE18/ PCIE19 of D27: F0/ F1/ F2/ F3, Graphics device should be primary
PCIE.
 Internal Graphics
"Auto or Disable or Enable" Internal Graphics.
 LCD Control
Figure 3.35 LCD Control
– LCD Control
Select Primary IGFX Boot Display (VBIOS Default, VGA, DVI1, DVI2).
