AIMB-785 User Manual 4
1.3.4 Graphics
 Controller:
 Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
 Triple display: 1 VGA (DB-15) +2 DVI-D in rear I/O.
 DVI-D: Up to resolution 1920 x 1200 @ 60 Hz refresh rate
 VGA: Up to 1920 x 1200 resolution @ 60 Hz refresh rate
1.3.5 Ethernet LAN
 Supports dual 10/100/1000Base-T Ethernet port (s) via PCIe x1 bus which pro-
vides a 500 MB/s data transmission rate.
 Interface: 10/100/1000Base-T
 Controller: Intel I219LM(PHY) for LAN1, Intel I211AT for LAN2
1.3.6 Industrial Features
 Watchdog timer: Can generate system reset or NC. The watchdog timer is pro-
grammable, with each unit equal to one second (255 levels)
1.3.7 Mechanical and Environmental Specifications
 Operating temperature: 0 ~ 60°C (32 ~ 140° F, depending on CPU)
 Storage temperature: -20 ~ 70° C (-4 ~ 158° F)
 Humidity: 5 ~ 95% non-condensing
 Power supply voltage: +3.3 V, +5 V, ±12 V, +5 VSB
 Power consumption: Intel Core i7-6700 3.4 GHz; DDR4 8 G x 4
Maximum: +3.3 V at 1.02 A, +5 V at 1.96 A, +12 V at 1.14 A, +5 Vsb at 0.08 A,
-5 V at 0.03 A, -12 V at 0.06 A
 Board size: 304.8 x 228.6 mm (12" x 9.6")
 Board weight:
1.4 Jumpers and Connectors
Connectors on the AIMB-785 motherboard link it to external devices such as hard
disk drives and a keyboard. In addition, the board has a number of jumpers that are
used to configure your system for your application.
The tables below list the function of each of the jumpers and connectors. Later sec-
tions in this chapter give instructions on setting jumpers. Chapter 2 gives instructions
for connecting external devices to your motherboard.
Table 1.1: Jumper list
Label Function
JCMOS1 CMOS Clear
JWDT1 Watchdog reset
PSON1 AT(1-2) / ATX(2-3) mode selector
JUSB_1
USB power source switch between +5 V and +5 V_ DUAL for Rear
USB ports
JUSB_2
USB power source switch between +5 V and +5 V_ DUAL for On
Board USB ports
JPCICLK1 PCI Clock selection (1-2): 66MHz/ (2-3): 33MHz (default)
